Four station balloon screen printing machine
Contact Us
Inquiry
Scope of application
This screen printing machine is suitable for printing logos, text and patterns on latex balloons.
Main parameters
| Model | TX-QQ150 |
| max printing area | 150*150mm |
| Mode of operation | semi-automatic |
| Max screen frame size | 700*1000mm |
| Rated voltage/Power | 220V/1KW |
| Print color | monochrome |
| Printing speed | 900-1200m/min |
| Inner diameter of balloon carrier | 150mm |
| Size of package | 1300*800*1300mm |
| Gross weight | 120(KG) |
Configuration instructions
① Microcomputer control each function, easy to operate, equipped with five automatic counter
② All pneumatic components adopt well-known brands, to ensure the machine quality
③ Front and rear oil scraping is driven by cylinder + linear bearing to ensure smooth and smooth movement
④ Screen lifting adopts cylinder + guide column drive.
⑤ The working table adopts the design of four stations, rotating one station every 90 degrees, automatic blowing, the size of balloon blowing
can be adjusted.
⑥ Oil-free three-point combination does not produce exhaust oil mist pollution, suitable for use in dust-free rooms
⑦Can be customized according to customer requirements, to meet different requirements
Machine maintenance
① Before going to work to clean up the debris on the machine, the machine will be wiped clean. To guide rail, guide pillar, bearing and other moving parts to regularly add lubricating grease.
② Workpiece table is a key component affecting the printing quality, to prevent the impact of hard objects, printing, can not put the ink. God that water and other organic solvents dripping on the work surface.
③ The electric control panel and keys should be prevented from being damaged by direct or indirect contact with solvents such as water, boiling
oil and water.
④ The frame paint is to keep the machine from rusting, to prevent direct or indirect contact with water, boiling oil and water and other solvents caused damage.
⑤ The sewage and dirt in the oil mist combiner should be discharged in time. To prevent it from being sent into the pneumatic components, which will affect the normal operation, clean the cup body regularly, and add PENG 2 lubricating oil into the oil cup of the oil mist combiner.
⑥ When adjusting the limit valve, it is necessary to loosen the forcing nut before adjusting it by hand. The handle screws on the machine are used for positioning. After firm positioning, there is no need to tighten them.
⑦ After work, turn off the power/air supply, clean the screen and keep it safe. Resistant to dust/pressure/hard objects piercing.
Accessories list
| No | Tool name | Spe | Unit | QTY |
| 1 | Power line | standar | PC | 1 |
| 2 | Foot switch | standar | PC | 1 |
| 3 | Cross screwdriver | standar | PC | 1 |
| 4 | monkey spanner | standar | PC | 1 |
| 5 | Hex Wrench | standar | PC | 1 |
| 6 | work-box | standar | PC | 1 |
| 7 | Operating instruction | PC | 1 |
TaoXing Company Introduction
Taoxing automatic screen printing machine video compilation
Service / FAQ
Guarantee
① We provide comprehensive one-stop services, customer training and satisfied after sales services.
② Online support, video technical support for troubleshooting manufacturing problems, engineers are available to service oversea as necessary.
③ Sold enjoy one year of free equipment warranty and lifetime technical support.
Guarantee for Delivery
Safety and fast logistic ensures the goods are delivered on the right time
1. Packing: Plywood Case for Each Machine
2. Payment terms: T/T (50% deposit to start the production, 50% paid before delivery)
3. Delivery date：60 business days after received the payment.
4. Departure of port: By sea from Shanghai or Ningbo
5. Delivery means: By sea by land
A: We are a professional manufacturing factory specialize in printing equipment with more than 20 years experience, committed to supplying our customer top quality and dedication to the constant improvements of quality, reliability, productivity and the competitiveness of our products and services.
A: Please send us an inquiry directly. We need to get specific details, such as material, size, color, thickness, quantity, etc.
A: Yes, we have a professional technique team, we could produce the machine depends on your requirements.
A: We accept TT/LC/PAYPAL/Western union, every payment term we can discuss.
A: All Taoxing products carry up to a full year warranty. Supply wearing parts with favorable price and long term after-sales service. We believe in total customer satisfaction, aside from our no-hassle guarantee.
Screen printing was a technique first used by the Chinese almost 2000 years ago. It is widely used at home and abroad. Chinese printing machine market has already become the focal point of the world have opened up. We have teams of experienced technical experts and professionals providing most professional and just-in-time technical consults and services, timely supply of spare parts in place.
If you are still confused how to start printing work, don’t worry, contact us and we will help you out!! No mater you are a green hand, we will train you up-to-date technology skills, and keep an eye on your business opportunities. Our friendly and professional team that is able to handle all your inquiries whenever you need.
